300 XRS4 Go Kart Trailmaster 300cc CVT Automatic with Reverse

300 XRS4 Go Kart Trailmaster 300cc CVT Automatic with Reverse

  • $4,149.95
    Unit price per
  • Save $2,280
Shipping calculated at checkout.


300 XRS4 Go Kart Trailmaster 300cc CVT Automatic with Reverse




The 300 XRS4 Go Kart Trailmaster 300cc CVT Automatic with Reverse features an 17 HP Powerful 300cc CVT fully automatic with reverse engine, air cooled. Steel Wheels with Large tires with 20X7-8 in the front and 22X10-10 in the back. It is made of heavy duty frame, net weights 608 lbs with a max load capacity of 800 lbs! Both front driver and passenger seats are adjustable with driver side pedal to center seat back adjustable from 41� to 46�, fits driver/passenger up to 6�2 in height!

This model also features an Adjustable heavy duty front and rear shock absorber which really works well to absorb every bump and rock along the way, Front and rear hydraulic disc brake, It is equipped with big front / rear tires of 20 x 7-8 / 21 x 10-10 and special gear ratio set up, plenty of power to take off and pull 4 people!

ORDER ONLINE OR
CALL NOW (866) 606-3991




We have done more business than
any retail go kart business ONLINE!

ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




Features & Specifications:

  • Engine type 4-stroke, single cylinder, air cooled
  • Displacement 300cc
  • Output Max. 17.4HP/6500rpm
  • Max torque 16 lb ft/5000rpm
  • Bore x stroke 2.85 x 2.63 inches
  • Max speed 50mph
  • Climbing ability 15 degrees
  • Min turning radius 229 inches
  • Ignition C.D.I
  • Starting system Electric Start
  • Battery 12V 10Ah
  • Gear oil MoS2&W-2WD-4D
  • Clutch Automatic CTV with reverse
  • Driveline / Driving wheel Chain / Dual wheel drive
  • Suspension, F / R Dual A-arm / swing-arm
  • Brakes, F Hydraulic brakes, Disc
  • Brakes, R Hydraulic brakes, Disc
  • Tires, F / R 20 x 7-8 / 22 x 10-10
  • Fuel capacity 2.25 gal
  • N.W. 608lbs
  • G.W. 758 lbs
  • Max load 800 lbs
  • Wheelbase 84.5 inches (2.23m)
  • OA L x W x H 116.1x54.5x59.2 inches
  • Height to seat,F 17 inches
  • Height to seat,R 18.2 inches
  • Distance between front and rear seat 25.6 inches
  • Min. ground clearance 15.8 inches
  • Pedal to center seat back 41 to 46 inches
  • 17 HP Powerful 300cc CVT fully automatic with reverse engine, Liquid cool
  • Heavy duty frame, net weight 608 lbs, max load 800 lbs, adult size 4-seat go kart
  • Digital speedometer/odometer
  • Stainless steel performance muffler
  • Five-point safety seatbelt
  • Adjustable steering wheel
  • Adjustable front driver and passenger seat: pedal to center seat back adjustable from 41� to 46�, fits driver/passenger up to 6�2 in height
  • Front seat to rear seat distance 26 inches, fits passengers up to 6�2 in height
  • Handled extremely well on trails, only Min. 229 inches turning radius.
  • Electric start with kill switch
  • Aluminum side mirrors
  • Sporting steering wheel
  • Turn signals
  • Individual sporting seats
  • Polished stainless steel muffler
  • Big tires: F / R: 20 x 7-8 / 21 x 10-10
  • Bikini sunshade top
  • Adjustable heavy duty front and rear shock absorber
  • Rack and pinion steering wheel
  • Front and rear hydraulic disc brake
  • 4-wheel fenders
  • Trailer hitch
  • Large gas tank
  • Horn
  • Padding over roll cage


ORDER ONLINE OR CALL NOW (866) 606-3991



ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




ORDER ONLINE OR
CALL NOW (866) 606-3991




***Go-Karts require an extensive amount of assembly. Typically it is recommended that you have a mechanic complete the assembly. Most Go-Karts available on our website require anywhere from 3-8 hours of shop time for assembly. Assembly generally involves, but is not limited to: installing wheels, role cage, bolting in seats, installing front/rear shocks and steering arms, installing fenders, securing rear swing arm, changing oil, adjusting carburetor and hooking up light wiring if applicable***
